IMPAQ PLUS
The Impaq Plus is a rugged, portable 4-channel spectrum analyzer with an IP65 industrial protection rating, making it suitable for measurements in harsh environments. It features a large 10.1-inch multi-touch color display, 24-bit signal acquisition DAQ, and a maximum measurement bandwidth of 40 kHz. The device covers all vibration and acoustic measurements and supports some ultrasonic meas-urement bands.
Spectrum Analysis
Fourteen Vibration and Noise Measurement Analysis Functions: Modal testing, Operating deflection shape testing (ODS), Envelope spectrum analysis, 3D Waterfall Plot, Intensity, Testing and analysis of varying speeds, Load changes, or Vibrations during startup, shutdown, or acceleration.
Octave Band Frequency Analysis
Using parallel time-domain digital filtering technology, it can simultaneously display 1/1 octave, 1/3 octave, and 1/12 octave spectra. The audio analysis includes built-in IEC 61260 and IEC 61672 standards, as well as vibration specifications with special weighting according to ISO 6954, ISO 8041, and ISO 2631 standards. It can also be used to measure floor vibration intensity using VC curves.
Order Tracking Analysis
Accurate measurement and analysis of the rotational speed order spectrum, order variation trends, filtered and unfiltered trajectories (Orbits), air gap variations, and shaft centerline during the start-up and shutdown processes of rotating machinery. Typical applications include NVH (Noise, Vibration, and Harshness) testing for vehicles and vibration problem analysis for turbine rotors.
Online Rotor Dynamic Balancing Analysis
On-site Rotor Dynamic Balancing Calibration for Rotating Machinery
Offers single-plane, dual-plane, cantilever dual-plane, three-plane, four-plane, and three-weight block balancing methods.
Additional features include: 1X deceleration testing, dual-plane conversion to three-plane (static + dynamic imbalance), unequal radius calculation, component calculation, drilling depth calculation, vibration history data, and dynamic balancing history data.
Optional software:
- FFT spectrum analysis
- Octave spectrum analysis
- Order tracking analysis
- Data recorder and playback
- Rotor balancing
